The new Creek Sequel phono boards are plug in boards compatible with all current Creek integrated amplifiers.
-
| Module type |
Sequel 40
|
|
Sequel 48
|
Sequel 54
|
| Gain |
100 (37 dB) |
|
250 (48 dB) |
1000 (60dB |
| Frequency Response |
20 Hz to 20 kHz +/- 0.25 dB |
|
20 Hz to 20 kHz +/- 0.25 dB |
20 Hz to 20 kHz +/- 0.25 dB |
| Signal to Noise Ratio |
- 83 dB |
|
- 83 dB |
- 73 dB |
| Cartridge compatibility? |
high output MM cartridges in the range of 3.5 mV - 5 mV output |
|
high output MC or low output MM cartridges in the range of 0.9mV -2 mV output |
low output MC cartridges in the range of 0.1 mV - 0.25mV output
|
| Output impedance |
100Ω |
|
100Ω |
100Ω |
| Input Sensitivity / Impedance/ Capacitance |
3.5 mV / 47K Ohm / 220pF |
|
1 mV / 47K Ohm / 220pF |
0.2 mV / 1000 Ohm / 3300 pF |
-
-
