Auto Setup
Detection of connected speakers
Speaker phase check
(absolute Phase)
Detection speaker size
(large/small)
Recognition of optimal crossover frequency
each speaker individually
Automatic time delay adjustment
(0,01 Metre increments)
Automatic level adjustment
(0,5 dB increments)
Accurate microphone
(included)
custom made by Audio-Technica
Power Amplifier
Type
5 channel amplifier
6 ohms, 1 kHz, THD 0,7%
Front L/R
Center
Surround L/R
Surround Back L/R
Front Height/Wide L/R
120 W + 120 W
120 W
120 W + 120 W
8 Ohm, 20Hz-20kHz, 0.05%
Front L/R
Center
Surround L/R
Surround Back L/R
Front Height L/R
80 W + 80 W
80 W
80 W + 80 W
Power amp construction
discrete
Large Aluminium Heatsink
Bandwidth
10 Hz - 100 kHz
Sound Formats
Dolby TrueHD
DTS-HD
DTS 96/24
DSP
Digital Circuit
D/A converter
24-bit / 192-kHz
A/D converter
24-bit / 96-kHz
Digital Interface Receiver (DIR)
24-bit / 192-kHz
Auto Room EQ
Operating mode
Audyssey MultEQ XT
Choice of EQ curves without re-measurement of the system
(Audyssey, Audyssey Flat, Audyssey Byp. Front, Manual)
Direct Mode with/without EQ
Auto Room EQ with Audyssey MultEQ
Simultaneous correction of room dependent frequency responses for up to 8 listening positions
up to 8 positions
Correction of the room acoustics in time and frequency domain
Audyssey Dynamic EQ
Audyssey Dynamic Volume
(3 Modes: Midnight, Evening, Day)
Features
Personal Memory Plus / Auto Surround
/
Dimmer
4 steps
(light, middle, dark, off)
Pure Direct Mode
(Turns off video,digital,display sections)
Direct Mode
Power On Volume Level
(LAST, ---, 1 dB Steps)
Chassis construction for High-quality Sound Reproduction
Quality selected parts
Bass Management frequency
slew rate low-pass/high-pass
40 / 60 / 80 / 100 / 120 / 150 / 200 / 250 Hz
Speaker terminals (also for 4mm plugs)
screw type
Audio Delay (Lip Sync)
(0-200 ms)
On Screen Display
Graphical User Interface (GUI)
- Language Support
- Screensavers
- Wallpaper
- Supported TV standards
- Display Time
English, German, French
(image, black)
PAL / NTSC
Configurable (Off, 10s, 30s, Always)
Setup Wizard for easy installation
(English, German, French)
Rename function for input names
(8 characters)
"Quick Select"
memories
4
Naming the "Quick Select" memories
(max. 16 signs)
Video Select Function
Remote Control
Presets / learnable
GLO-KEYS / backlight Keys
Macro function
Denon Remote App
Compressed Audio Restorer
iPod Functionality
(direct via USB)
USB-Functionality
- Control Interface from Remote
- Audio Playback
- Photo Playback
- Control from Menu
- On Screen Display
Memory Sticks, USB-Player, iPod, USB-HDD
MP3, WMA, WMA (DRM), AAC (w/o DRM), FLAC-HD, WAV
JPEG (SD quality)
(GUI, FL-Display)
Direct USB digital connection for iPod (audio only)
Ethernet-interface for Media-Streaming
Firmware-Update via Ethernet
- via PC
- direct via GUI
-
Internet Radio
- Supported Format
- Number of Stations
- Configurations via
www.radiodenon.com
MP3, WMA
approx 12.000
Internet radio presets
3
Last.FM subscription service access
(UK/Germany)
AirPlay
Streaming from Media Server
(PC, NAS)
- DLNA certified
- Audio Streaming format
- Photo Streming format
- Slide show
- Slide show with music
- Displays Album Artwork
MP3, WMA (DRM), AAC (not DRM), FLAC, WAV
JPEG
Network Party Mode
Web Control/Setup
- via web browser / PDA
- Save/Load the configuration from the PC
/
/
Sleep Timer
HDMI
HDMI Switching
- input
- output
5 (incl. front)
1
Video-Function
- max. resolution
- Deep Colour (30, 36 Bit)
- xv.YCC
1080p (24, 50, 60 Hz)
3D Pass-Through
- Frame Packing
- Side-by-Side
- Top-Bottom
Video Signal processing
Analog -> HDMI
- Converting
- i/p
- Progressive Mode
- Scaler
- Video EQ
-
-
-
-
-
Auto Lip Sync
HDMI CEC compatible
Audio Return Channel (ARC)
Connections
Digital Inputs optical / coaxial (freely assignable)
1 / 1
Analogue Audio inputs
2
Pre-Amplifier Outputs
Subwoofer
Video Inputs Composite / S-Video
2 / -
Video Outputs Composite / S-Video
Monitor / -
HDMI / DVI-D Inputs
5 / -
HDMI / DVI-D Outputs
1 / -
Headphone output
(6.3 mm Jack)
Ethernet
USB interface for USB Memory Sticks and USB players
1 (Front)
Multi Room / Home Automation
Ethernet Connection
- for Media streaming
- for PC (PC-Control)
Enhanced Multi Room functionality
Tone and balance control
Power On Level, Volume Limit, Muting Level adjustable
Tuner
RDS / Radio Text
/
Preset memory
56
General
Dimensions (width x height x depth)
435x151x332
Weight
8.3 kg
Power consumption (Stand-by)
0.1 Watt
< 1.5 Watt (CEC activated, no signal)
< 3 Watt (CEC activated, with signal)
< 2 Watt (Network standby)
Launch date
5.2012
Available in
Black
