Pioneer A70 Integrated amplifier
The flagship 2 channel amp in the range, the Pioneer A-70 is not only a powerful stereo amp with a myryad of analogue and digital inputs, but also it features a high quality 24 bit 192kHz asynchronous DAC making it the ideal centre piece for a modern, streaming stereo system.</p><br /><p>A low distortion 90W class D stereo power amplifier forms the basis of the Pioneer A70, wotking in tandem with a flexible pre-amp with a MM/ MC phono stage. Analogue inputs for CD, SACD, Tuner and tape loop can be found, whilst bypassable tone controls and speaker AB switching add to it's appeal
-
Main Features of Pioneer A-70
Output Power per Channel90W
Impedance at Output Level• 4 Ω - 16 Ω (A / B)
• 8 Ω - 32 Ω (A + B)
• 4 Ω - 16 Ω (Bi-wiring)
Number of Channels2
Input Connections• SACD/CD
• Phono (MM/MC)
• Aux
• Network
• Digital Coaxial Input
• Recorder
• Tuner
• Power Amp Direct In
• USB
• SR In
Output Connections• Recorder
• Phones
• SR Out
Remote ControlMulti-functional remote control
Input & Output connections
Digital Coaxial InputYes
Headphone InputYes
Large speaker terminalsYes
Phono InputYes
Pre-amp Output Yes
Speaker A/BVersatile speaker configuration
Audio Features
Bass/Treble Tone ControlsYes
Power Output
Power output per channel90 W
Condition20 Hz - 20 kHz, THD 0,5%, 4Ω
Rated Power Output90 W per channel
Power RequirementsAC 220 - 230 V / 50 Hz
Power Consumption (in use / standby)74 W / 0.2 W
Auto Power DownYes
Construction
AIR Studio Sound Tuning (+)Yes
Design• Separated Construction for Preamp and Power Amp
• Twin Block Shield Transformer
• Source Direct Mode
• DAC Mode
• Clean Ground Construction
• Isolated Power Supply
• Trans-Stabiliser
• Rigid Under Base
• Solid aluminium volume knob and front/ side panels
• Gold-plated Speaker Terminals (large type)
• Gold-Plated Analogue Audio Terminals
• High-Grade AC Power Cord
Amplifier Specifications
AmplifierMOSFET Class D Amplifier
D/A Converter• ESS SABRE32 192 kHz/32-bit Audio DAC
• Asynchronous 192 kHz/32-bit USB DAC
Dimensions (W x H x D)435 x 141.5 x 361.5 mm
Weight17.1 kg
-
-
