DetailsTrue 500W (continuous) discrete, direct-coupled MOSFET amplifier 2x downward-firing long-throw 250mm (10") very heavy duty Volt drivers , die-cast chassis Refined ABC variable crossover adjustment in 24 musically correct semi-tone increments between 24Hz-106Hz. Acoustic Resistive Matrix (ARM) loading for smoother bass response Four position mode selector: line/LFE (0 degrees phase and 180 degrees phase) Audiophile grade toroidal transformer Gas-tight Neutrik high level connection for long-term consistency of sound quality High quality, panel-mounted twin phono inputs at 0dB and +12dB (low level) High and low level balanced inputs (Neutrik/XLR) Totally discrete input circuitry for high and low level inputs Separate volume controls for high and low-level adjustment Simultaneous connection of high and low level sources Set-Safe audibly transparent driver protection Balanced-bridge power supply 8x ultra-rugged output devices Double thickness, double-sided glass-fibre board with plated-through holes IEC power input socket - no captive leads for installation flexibility Hand-built in Great Britain, three year worldwide warranty
System TypeARM loaded cabinet with ABCÆ semi-tone variable bass
filter. 110 litre.
Lower Frequency Response:(in room -6dB): 9Hz
Amplifier Input impedance High level 100 kohm
Gain Control Range:Low level 10 kohm 80dB
Drive unit impedance:8 ohm
Mains input voltage:115 V 50/60 Hz or 230 V 50/60 Hz,
subject to country
Dimensions WxHxD mm (inches)
incl. feet and rear panel controls
685x617x567 (26.99 x 24.31 x 22.34)
Weight Kg (lbs)93 (205.03)
Finishes:black oak light oak rosenut
