Dynavector 20X2a MC Phono cartridge

The DV 20X2A is a basic model of the Dynavector MC cartridge series. Using the same base structure as our higher-end models XX-2A and Te Kaitora Rua, it has a solid aluminium alloy body, hard aluminium cantilever and a Micro-Ridge stylus tip.

This DV 20X2A has 2 types for you to choose from according to your system. The 20X2A-L (low output model) has the output as a regular MC cartridge while the 20X2A-H (high output model) is an MC cartridge that is suitable for most MM inputs.

Key Features

• High and low output options
• Micro ridge stylus tip
• Aluminium pipe cantilever
• High-quality neodymium magnets
• Tracking force 1.8 - 2.0g

This cartridge is ideal not only for those who want to fully enjoy the sound of an MC cartridge but also for those who would like to easily experience the charms of an MC cartridge without the need to use an MC step-up transformer.

High Output Model / Low Output Model

The high-output model 20X2A-H achieves an output voltage of 2.8mV by using Dynavectors legendary coil winding technology. By winding the coil many times with ultra-fine wire, the cartridge can obtain a high output equivalent to an MM cartridge. This allows the MC cartridge to be connected to the PHONO terminal for MM input without the need for a head amplifier or step-up transformer.
The low-output model 20X2A-L has a 0.3mV output voltage, using the same PCOCC wires as the higher-end models for the coil. The recommended load impedance of the head amplifier is 30Ω or more, making it compatible with most head amplifiers and MC step-up transformers.

The magnetic circuit, which is the core of an MC cartridge, uses pure iron that has stable magnetic properties with minimal distortion. Furthermore, by performing special annealing that focuses on optimizing the magnetic annealing process such as annealing temperature, environment, heating duration, and heating/cooling rates, we have succeeded in delivering expansive resonant sound without distortion and unrivalled resolution.

Neodymium magnets

The series employs patented softened magnets developed to reduce distortion and harsh irritating edgy sounds caused by rare earth magnets while still achieving high output from powerful neodymium magnets. While taking advantage of the powerful magnetic force of neodymium magnets the cartridge achieves a clear separation of sound.

Micro ridge stylus

A Micro-Ridge stylus is used for the stylus tip. Although the part that contacts the record groove has a minute radius curvature of only 2 microns, the band-like shape of the tip makes it resistant to abrasion and will provide ideal performance over a long period of time.

Special Annealing Magnetic Circuit

The magnetic circuit, which is the core of an MC cartridge, uses pure iron that has stable magnetic properties with minimal distortion. Furthermore, by performing special annealing that focuses on optimizing the magnetic annealing process such as annealing temperature, environment, heating duration, and heating/cooling rates, we have succeeded in delivering expansive resonant sound without distortion and unrivalled resolution.

Who is Dynavector?

Dynavector is one of the world’s leading manufacturers of high-performance moving coil cartridges and has been at the top of its game for over four decades. Using their patented magnetic flux damping and softened magnetism mechanisms, Dynavector’s range of cartridges is certainly innovative. Hearing a standard moving magnet cartridge and Dynavector’s moving coil cartridges you’ll be blown away by the difference in sound.

From their entry-level, MC 10X5 cartridge to the top-of-the-range DRT XV-1t, Dynavector cartridges can help take your listening experience to the next level. Their high-output models are designed to work with MM inputs, perfect for those just starting their upgrade journey in the world of vinyl.

Founded in the mid-1970s by Dr Tominari in Tokyo, Dynavector is committed to delivering the best quality sound from vinyl. As a former physics professor at Tokyo University, Dr Tominari had a lifelong interest in music and his scientific background helped him to design, develop and produce truly innovative products. This has continued to this day and helped Dynavector become synonymous with great-sounding vinyl.
